BLACKMAGIC DESIGN MINI CONVERTER SDI TO ANALOG 4K - конвертор Blackmagic Mini Converter SDI to Analog 4K включва всичко необходимо за конвертиране от SD, HD, 3G и 6G‑SDI видео към аналогово в HD/SD компонент, NTSC и PAL видео. Вграденият конвертор надолу означава, че можете дори да свържете Ultra HD източници към компонентно видео в SD или HD, както и NTSC и PAL видео! Свържете лесно всяко аналогово оборудване като Betacam SP, VHS и видео монитори.
| SD Video Standards | 525i59.94 NTSC, 625i50 PAL |
| HD Video Standards | 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60 |
| 2K Video Standards | 2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF |
| Ultra HD Video Standards | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30 |
| 4K Video Standards | 4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p |
| SDI Compliance | SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE ST‑2081, ITU‑R BT.656 and ITU‑R BT.601 |
| SDI Video Rates | SDI video inputs are automatically detected between standard definition and high definition. |
| SDI Video Sampling | 4:02:02 |
| SDI Audio Sampling | Television standard sample rate of 48 kHz and 24 bit. |
| SDI Color Precision | 4:02:02 |
| SDI Color Space | YUV |
| SDI Auto Switching | Automatically detects SD and HD. |
| Analog Format Support | 525i59.94 NTSC, 625i50 PAL, 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080i50, 1080i59.94, 1080i60 |
| Analog Color Space | YUV |
| Analog Color Precision | 4:02:02 |
